Linkit Surface Box Transmitter
With its global connectivity, long battery life and robustness, the Linkit SB is both easy to use and ideal for equipment recovery & long-term monitoring, needing less trips out to sea, saving you time and money.
Discover its Main Features
Works with simple AA batteries and easily attached with cable ties
Up to 5 years
of battery life
Limits risk
of equipment loss
Reduces costs with less
missions out to sea
Main Features
Argos
- TX Output Power: 250mW to 1W
- RX for Satellite Pass Predicition
Antenna
- Argos: External helical (75mm)
- GNSS: Internal patch
Box Features
- Measures: 12.7 x 7.9 x 3.8cm
- Weighs: 415g (without batteries)
- Withstands Temperatures: from -20°C to 50°C
- Water Resistance: IPX7
Consumption
- Argos TX (<1sec burst): 220mA
- GNSS RX ZOE-M8: 27mA
- Sleep Mode: 0.049mA
Configuration
Configurable via bluetooth with GenTracker App (iOS/Android)
GNSS
- Uses GPS/GALILEO/QZSS/GLONASS
- Position acquisition can be programmed for every:
- 10, 15 or 30 minutes
- 1, 2, 6, 12 or 24 hours
- Argos Doppler positioning also available
Battery
For longer battery life we recommend using 6 AA Energizer Ultimate Lithium L91 – 1.5V batteries
